Here are just some of the features:

1. It offers ultimate flexibility in both machining and length cutting of uPVC profiles. Totally 12 servo motors and servo drivers are equipped with the machine.
2. Feeding-in manipulator controlled by 3 servo motors.
3. Can auto feed 9 profiles at one time. High production efficiency.
4. 4 spindle motors are positioned at top, bottom, back and fronts 4 sides. One of the spindle motors can be rotating at any degree between 0°-90° degree for water slot milling.
5. 4 spindle motors are driven by 7 servo motors and servo drivers for milling and drilling processing.
6. 550mm diameter saw blade controlled by the servomotor rotated at 45°-135° degree for flexible cutting requirement.
7. Off-loading unit is controlled by servo motor-controlled gripper with gently pulling out and positioned, even for super short size profile.
8. Can print the bar code on production, easy for production management.
9. The pneumatic-electric protective devices and mechanical protective devices ensure safety in production.
10. Waste collection: equipped with automatic chip removal machine, automatic collection of processing waste, and the site is tidier.
11. Fully covered cabinet to assure less working noise and tidy working area. Internal 360-degree camera and external display assist operator monitoring working actual working.
12. Fully compatible with the likes of Business Micros and First Degree.
13. Short lead times, on average from receipt of order to delivery is 3-4 months.
14. Option to add the ASU auto reinforcing screwdriver for even more flexibility.
